PVC Insulated Copper Wire H07V-U H05V-K H07V-R H07V-F cable



CONSTRUCTION
Conductor
Class 5 flexible copper conductor according to
BS EN 60228 (previously BS 6360)
INSULATION
PVC (Polyvinyl Chloride) Type TI1 according to BS EN 50363
CHARACTERISTICS
VOLTAGE RATING (UO/U)
H05V-K: 300/500V
H07V-K: 450/750V
TEMPERATURE RATING
Fixed: -30°C to +70°C
Flexed: -5°C to +70°C
MINIMUM BENDING RADIUS
12: 5 x overall diameter
12: 6 x overall diameter
SHEATH COLOUR
Red Black Blue Orange Yellow White
Green Grey Brown Violet Pink
CONSTRUCTION

Single croe and Multi Core Cable.Soild or Stranded Plain copper ,PVC insulated and PVC sheathed.
